Steel Wheel Rim 16X22.5 for Agricultural Machinery, Floatation, Forestry, Havesty, Trailer

Still deciding? Get samples of $ !
Request Sample

Product Description

Basic Specifications
Model NO.: 16x22.5
Diameter: 15-16"
Type: Tubeless
Certification: ISO, DOT, CCC, ECE
Usage: Tractors, Harvesters, Cultivators
Tire Design: Radial Tyre
Main Market: Europe
Package: Pallets
HS Code: 870870
Origin: China
Product Description
Steel Wheel Rim 16X22.5 for Agricultural Machinery
Inch Wheel Size Tyre Size Part Number P.C.D (mm) Center Hole (mm) Hole Type Bolt Holes Offset (mm)
22.5 16.00x22.5 550/45R22.5, 550/60R22.5, 560/45R22.5, 550/60-22.5, 500/45-22.5 161335A3P0 335 281 A3 10 0
161335B3P0 335 281 B3 10 50
161335B333P0 335 281 B33 10 0
161275A3N50 275 221 A3 8 Negative 50
161205A2P0 205 161 A2 6 0
Extended Range of Sizes
Inch Wheel Size P.C.D (mm) Center Hole (mm) Hole Type Bolt Holes Offset (mm)
15.39x15.3125/140/20590/94/161A1/A25/60/15
15.513x15.5205161A260/N35
16W6x16 / W8x16150/20590/161A260/50
1713x17 / 16x17205161A260
17.55.25x17.5 to 6.75x17.5205/275161/221A2/B26/80 to 145
19.56.75x19.5 to 14.00x19.5205/225/275161/176/221A2/A36/8/100
22.57.50x22.5 to 20.00x22.5203/205/275/335152/161/221/281A2/A3/B36/8/10Various
26.520x26.5275/335221/281A3/B28/100/N50
32DW27x32275/335221/281A3/A48/100/N50/N74
38DW23x38586510H33160
Frequently Asked Questions
1. What types of machinery are these steel wheel rims suitable for?
These wheel rims are designed for heavy-duty agricultural machinery, including tractors, harvesters, cultivators, forestry equipment, and trailers.
2. What quality certifications do these wheel rims carry?
All wheel rims meet international standards and are certified by ISO, DOT, CCC, and ECE, ensuring high safety and durability.
3. Can these rims be used for tubeless tire applications?
Yes, these are tubeless-type radial wheel rims, which provide better heat dissipation and reduce the risk of sudden deflation.
4. What is the material used for the construction of these rims?
The rims are manufactured from high-strength steel, specifically designed to withstand the rigorous demands of agricultural and forestry environments.
5. Are custom specifications like different bolt hole patterns available?
Yes, customization of bolt holes (P.C.D), center hole diameters, and offsets is available to match specific machinery requirements.
6. How are the products packaged for international transport?
The wheel rims are securely packed on pallets to ensure stability and protection during sea or land transportation to global markets.
